V-Twin Mfg Billet Wagner Style Rear Master Cylinder 5/8 Bore for 1958-1979 Harley-Davidson FL FX

Part #:23-3004

$129.95$119.958% OFF

-

Chrome billet upgrade for 1958-1979 Harley-Davidson FL and FX models: Wagner-style 5/8-bore rear master cylinder CNC-machined for multi-piston caliper compatibility on Big Twin restorations.

  • ShippingFree over $99
  • Sales tax0% outside SD
  • Usually ships1 to 2 business days
(605) 498-0105 M–F | 9:00–4:30 CST90-Day ReturnsExpedited & international shipping

V-Twin Mfg Billet Wagner Style Rear Master Cylinder 5/8 Bore for 1958-1979 Harley-Davidson FL FX

For a vintage Big Twin restoration or a period-correct custom build, the master cylinder sets the tone for every stop the bike will ever make. This V-Twin Mfg Wagner reproduction installs in the original bracket location and delivers the brake pedal authority riders of this era expected, solid, direct, and dialed in from the first press.

Key Features

  • Reproduction of the original Wagner offset-mount design for correct installation on 1958-early 1979 Big Twin frame locations without modification
  • Offset mounting geometry distinguishes this from the Kelsey Hayes inline style, verify your mounting hole pattern before ordering
  • 5/8″ bore pairs with multi-piston aftermarket calipers for upgraded braking performance over the stock single-piston setup
  • 1/8-27 NPT inlet is compatible with standard hard-line brake fittings
  • Suitable for period-correct restorations and custom chopper and bobber builds with matching 2.25″ bracket spacing

Technical Specifications

Bore Size
5/8″
Style
Wagner offset mount
Inlet Size
1/8-27 NPT
Mounting Hole Diameter
3/8″
Mounting Hole Spacing
2.25″ on center
Mounting Offset
3/8″
Length
4″
Width
1.5″
Height
3.125″
Construction
Chrome-plated billet aluminum
Fluid Requirement
D.O.T. 5 Silicone Brake Fluid (recommended)
OEM Cross-Reference
41761-58 (1958-1972), 41761-78 (1973-1979)

Fitment Notes

  • 1979 fitment applies to early production only; late 1979 models transitioned to the Kelsey Hayes inline mount, see Kelsey Hayes master cylinder listings
  • Wagner offset mount is NOT interchangeable with Kelsey Hayes inline brackets, verify your mounting hole pattern before ordering
  • 5/8″ bore requires multi-piston aftermarket calipers; verify caliper bore requirements before installation
  • D.O.T. 5 Silicone brake fluid recommended; verify compatibility with your caliper manufacturer
  • Bench bleeding strongly recommended before final installation
  • Custom applications require 2.25″ center-to-center bracket spacing
  • Review the Fitment tab for the complete year and model breakdown

V-Twin Mfg Billet Wagner Style Rear Master Cylinder 5/8 Bore for 1958-1979 Harley-Davidson FL FX - Fitment

This master cylinder fits 1958-early 1979 Harley-Davidson FL and 1971-early 1979 FX models as listed below. All 1979 entries apply to early production only; late 1979 models use the Kelsey Hayes inline mount.
Years Model Code
FL Platform
1958-1964 Duo Glide FL
1958-1970 FS Series FS
1965-1979 Electra Glide FLH
1977 Electra Glide Sport FLHS
1965 Electra Glide Super Sport FLHFB
FX Platform
1971-1979 Super Glide FX
1974-1979 Super Glide FXE
1977-1979 Low Rider FXS
Weight 1 lbs
Dimensions 5 × 3 × 1.5 in
