Twisted Choppers XL Sportster Offset Trans Sprocket 22 Tooth 530 Chain 1 Inch Offset for 1957-1990
Get the offset transmission sprocket you need to run a wide rear tire on your Ironhead or early Evolution Sportster build without compromising chain alignment. CNC machined and heat-treated for precision and long-term strength, these USA-made sprockets are the right foundation for any hardtail or wide tire conversion on a vintage Sportster.
Key Features
- CNC machined for dimensional precision and accurate tooth profile
- Heat-treated for high strength and long wear life
- Designed for 180-200mm wide rear tire applications with hardtail frames and wide tire kits
- Covers 1957-Early 1984 (6 spline) and Late 1984-1990 (19 spline) XL Sportster transmissions
- 530 chain compatible
- Made in the USA
Technical Specifications
- Offset: 1″
- Total Offset: 1.35″
- Tooth Count: 22
- Chain Type: 530
- Spline Options: 6 spline (1957-Early 1984) or 19 spline (Late 1984-1990)
- Application: 180-200mm wide tire
- Origin: Made in the USA
Fitment Notes
- Select variation by spline count – 6 spline for 1957-Early 1984, 19 spline for Late 1984-1990 XL Sportster
- Designed for wide tire kits and hardtail frame builds
- Confirm your transmission spline count before ordering
- Review the Fitment tab for model and spline breakdown
john sully –
Good quality value for money.
James Lay –
Good fitment
