Exile Cycles Hidden Cable Internal Twist Throttle For 1 Inch Bars

Exile Cycles Hidden Cable Internal Twist Throttle For 1 Inch Bars

The Exile internal twist throttle is the detail that separates a truly finished custom from one that is simply assembled — routing the throttle cable invisibly through the bars eliminates the last exposed line from the cockpit and gives the front end the uncluttered, purposeful look that serious builders work toward. The roller-bearing action means the throttle feels as refined as it looks, snapping cleanly shut on every release.

Key Features

• Routes the throttle cable internally through the handlebar, eliminating all visible cable runs from the cockpit for a clean, minimalist front end
• Roller-bearing mechanism delivers smooth, precise throttle action and reliable snap-shut return
• Converts carburetor operation to a single-cable pull action — compatible with S&S, Mikuni, and other cable-driven carburetors
• Grip side diameter matches the Harley-Davidson throttle sleeve, allowing use of any grip that fits the standard HD sleeve
• 160 degrees of rotation with 1.25″ of cable travel for responsive, progressive throttle feel
• Handlebar side can be machined to a smaller diameter if required for specific bar or fitment applications
• Throttle assembly only — pair with your choice of cable for a fully custom routing solution
• Made in the USA

Technical Specifications

• Kit Contents: Throttle assembly only — cable not included
• Handlebar Compatibility: 1″ OD bars only
• Throttle Action: Single cable pull
• Rotation: 160 degrees
• Cable Travel: 1.25″
• Handlebar Side Length: 1.79″
• Handlebar Side Diameter: 0.825″ (machinable to smaller size)
• Grip Side Length: 4.03″
• Grip Side Diameter: 1.15″ (matches Harley-Davidson throttle sleeve)
• Bearing Type: Roller bearing
• Country of Origin: USA

Fitment Notes

• Fits 1″ handlebar grips only — does not fit 7/8″ bars under any configuration
• Requires a cable-driven carburetor or throttle body — will not work with Harley-Davidson Throttle by Wire (TBW) systems
• Throttle cable is not included — must be sourced separately and routed smoothly through the bars for correct snap-shut return
• Compatible with any grip that fits over a standard Harley-Davidson throttle sleeve
• Handlebar side diameter of 0.825″ can be machined down if a smaller dimension is required for specific installations
• Review the Fitment tab for complete compatibility information
